1. Equipment Supply List
No. | Name | Model | Quantity | Brand | Remarks |
Mechanical Parts | |||||
1 | Tail Fender | SG2307A -01 | 1 | Chinese Brand |
|
2 | Platform Base | SG2307A -02 | 1 | Chinese Brand |
|
3 | Tail Adjustment Device | SG2307A -03 | 2 | Chinese Brand |
|
4 | Center Frame Device | SG2307A -04 | 4 | Chinese Brand |
|
5 | Feed and Outlet Roller Channel Device | SG2307A -05 | 5 | Chinese Brand |
|
6 | Vertical Plate Turning Device | SG2307A -06 | 4 | Chinese Brand |
|
7 | Access and Outgoing Roller Rod Device | SG2307A -07 | 1 | Chinese Brand |
|
8 | Center Frame Pull Rod Device | SG2307A -08 | 1 | Chinese Brand |
|
9 | Vertical Flip Drive | SG2307A -09 | 1 | Chinese Brand |
|
10 | Vertical Flip Pull Rod Device | SG2307A -10 | 1 | Chinese Brand |
|
11 | Protection Hook Device | SG2307A -11 | 3 | Chinese Brand |
|
12 | Induction Switch Device | SG2307A -12 | 1 | Chinese Brand |
|
Electric Elements | |||||
13 | PLC | Smart 200 | 1 | Siemens |
|
14 | Frequency Transformer | ATV series | 1 | Schneider |
|
15 | Distribution Box |
| 1 | American/Italian Electric Cabinet |
|
16 | Proximity Switch | Ni50-CP80-AP6X2 | 4 | TURK |
|
17 | Low Voltage Electrical Components |
| 1 | Schneider |
|
18 | Button Switch |
| 1 | Shanghai |
|
19 | Air Cylinder |
| 1 | AirTac |
|
20 | Wire and Cable |
| 1 |
|
|
2. Design and Manufacturing Standards
The equipment and materials supplied by the Seller shall be designed, manufactured and inspected according to the following national standards and the standards and specifications confirmed by the Buyer:
⑴ Mechanical drawing standard: GB/T4457-4460-84 GB131-83
⑵ Tolerance coordination standard: GB/T1800-1804-79
⑶ Position tolerance standard: GB/T1182~1184-1996
⑷ Product inspection standard: JB/T5000.1-1998
⑸ Fire cutting parts standard: JB/T5000.8-1998
⑹ Welding parts standard: JB/T5000.3-1998
⑺ Forgings standard: JB/T5000.8-1998
⑻ Cutting machining parts standard: JB/T5000.9-1998
⑼ Assembly standard: JB/T5000.10-1998
⑽ Pipe matching standard: JB/T5000.11-1998
3. Assessment and Acceptance
Trial production specifications: synchronize with the trial production of host CNC lathe.
